参数表节选：

General specifications

Switching function Normally open (NO)

Output type PNP

Rated operating distance 4 mm

Installation flush

Output polarity DC

Assured operating distance 0 ... 3.24 mm

Reduction factor rAl 0.39

Reduction factor rCu 0.35

Reduction factor r304 0.75

Nominal ratings

Operating voltage 10 ... 60 V

Switching frequency 0 ... 800 Hz

Hysteresis typ. 5 %

Reverse polarity protection reverse polarity protected

Short-circuit protection pulsing

Voltage drop ≤ 2.5 V

Rated insulation voltage 60 V

Operating current 0 ... 200 mA

Off-state current 0 ... 0.5 mA typ. 0.1 μA

No-load supply current ≤ 15 mA

Switching state indicator LED, yellow

Functional safety related parameters

MTTFd 1530 a

Mission Time (TM) 20 a

Diagnostic Coverage (DC) 0 %

Approvals and certificates

Protection class II

Rated insulation voltage 60 V

Rated impulse withstand voltage 800 V

UL approval cULus Listed, General Purpose

CSA approval cCSAus Listed, General Purpose

CCC approval Certified by China Compulsory Certification (CCC)

E1 Type approval 10R-04

Ambient conditions

Ambient temperature -40 ... 85 °C (-40 ... 185 °F)

Mechanical specifications

Connection type cable PUR , 2 m

Core cross-section 0.75 mm2

Housing material brass, nickel-plated

Sensing face PBT

Housing diameter 12 mm

Degree of protection IP69K

Mass 120 g

General Notes Relating to Pepperl+Fuchs Product Information
